Phase II - EJ7IBD Inishbofin Island DMR On Air

On Sunday the 21st of July EJ7IBD, the Inishbofin DMR Repeater located on the east end of Inishbofin island, was installed and appeared on-air making it the first repeater to be established on an offshore Island. This Repeater will cover the western side of Connemara, including the coastal roads. There would be no way of covering this area from the Galway side of the mountains.

The 4-Stack directional antenna system, supplied by Radio Structures Ltd, plus feeder was installed on the mast on Saturday by Des, EI5GT, and Ronan EI8HJ. The antenna was fitted the 10m high tower beaming east towards the mainland. The antenna is solid and will last the weather conditions on the western coastline.

The 4-Stack Vertical Array

View to the Mainland

Steve, EI5DD, sailed out on the Sunday with the Repeater and ancillary equipment. Aengus, EI4ABB, fine-tuned the PROCOM Filters into the antenna system before the Repeater was connected. Ronan EI8HJ, and Des EI5GT, set up the Internet prior to connection of the Repeater.

The Repeater CPS was fine-tuned, loaded, and interfaced into the Brandmeister System via the Internet. On power-up, the repeater came to life and immediately connected into the Brandmeister Network. The initial transmission, on boot-up, did not indicate any feedback into the receiver and no desense was detected.

All systems worked well and the connection showed up on the Brandmeister Dashboard. A Few Calls were made through the system with Ronan EI4KN as our first contact. Final checks were made before increasing the power to 40 watts. A few more Calls were put out to prove that there was no desense with full power output. Finally, all the gear was tidied up and the remote GSM switch installed.

The Repeater fitted in well with the Wireless Internet system and didn't take up too much space.

Special thanks to Aengus EI4ABB for his assistance with the Cavity Filter tuning and to Ronan, EI8HJ, and Des, EI5GT, for Their assistance with the Networking and for the use of their mast and hut for the Repeater.

L - R - Des EI5GT, Aengus, EI4ABB,  and Ronan, EI8HJ

The map above shows the coverage of the Inishbofin Repeater bringing in a substantial area of the coastal road. The coverage may be better than illustrated as the worst-case scenario was programmed in to obtain the coverage.

       The combined coverage of EI7RHD - Galway, and EJ7IBD Inishbofin Island

The combined coverage of Inishbofin Island - EJ7IBD and Galway City - EI7RHD are only the beginning. EI7LRD - Loughrea and EI7AKR will follow fairly soon thus completing the Galway DMR Network. Inishbofin and Galway City are the two westerly Repeaters and the addition of Abbeyknockmoy and Loughrea Repeaters will complement the coverage. Uniform coverage with saturation of the majority of the county will be possible along with coverage into neighbouring counties.

Roaming between repeaters will be possible so constant contact with the network will be possible. The Loughrea Repeater will be the next one to be placed on site.

Read More

Castlebar 4 days Walking Festival 2019

Steve EI5DD, and Tom EI2GP, assisted with the communications for the 30 km rambles during the Castlbar International 4 Days walking Festival from the 4th to the 7th of July. We have been assisting with this event since 1992. There were over 260 international ramblers participating. There were twice that number participating in the Road Walks but we were not involved in that section.

The Marshals Organisers and Medical personnel were issued with PMR 446 radio equipment. The PMR 446 radio equipment allowed the Marshals, Walk Leaders, Medical and First Aid personnel to communicate with each other throughout the 30 Km Rambles over boggy terrain and in the hills. Steve, EI5DD, "Ground Control", was also in touch via the same system and also with Tom EI2GP who was using 2 metre Equipment which had wider coverage to the ground station. It was via the 2 metre system that any additional assistance could be summoned as this would be free of any other traffic.

There were four different routes:

Day 1 - Letterkeen Loop

Day 2 - Achill Island

Day 3 - Mulranny

Day 4 - A Scenic "Roady" walk through the Castlbar Countryside

As can be seen, the weather conditions were variable but never severe and any rain was only a light and misty. The conditions for walking were perfect and it was not too hot. There were many different walking terrains making it an interesting walk and provided many challenges walking across bog and hill. .

The APRS map of the 4 days is shown below. The Letterkeen Loop did not show up too well as it was situated well behind hills and out of range of almost everything. Our Communications worked well but there was a contingency plan if additional help were required.

The map below shows the entire travels of EI5DD for the 4 days plus travel to and from the event.

In conclusion, the event was very enjoyable from both our perspective and that of the walkers. Our radio equipment functioned perfectly. The Marshals, First Aid and Medical personnel learned radio procedure very quickly and were really proficient throughout the event. They would put some radio amateurs to shame! The liaison between the two systems was excellent and all equipment worked perfectly. We always try to introduce something new to events in which we participate but this particular event cannot be improved beyond its current format.
